| Brand | TP-LINK |
| Model | TL-MR100 |
| Standards | IEEE 802.11b/g/n |
| Antennas | 2 Detachable External 4G LTE Antennas |
| Transmit/Receive | < 20 dBm (2.4 GHz) |
| Frequency | 2.4 GHz |
| Wireless Functions | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics |
| Interface | 1 10/100Mbps LAN Port, 1 10/100Mbps LAN/WAN Port, 1 Micro SIM Card Slot |
| Button | WPS/Reset Button |
| Management | Local Management, Remote Management |
| 4G/3G/2G | 4G : FDD-LTE: B1/B3/B5/B7/B8/B20 (2100/1800/850/2600/900/800 MHz) TDD-LTE : B38/B40/B41 (2600/2300/2500 MHz) 3G : HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz) |
| System Requirements | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Micro SIM Card |
| Power Supply (PoE) | 9V/0.85A |
| Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Certification | CE, RoHS |
| Package Contents | 300 Mbps Wireless N 4G LTE TL-MR100 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| Dimension | (W x D x H) : 15.40 x 11.40 x 3.60 cm |
| Net Weight | 0.00 KG |
| Package Dimension | (W x D x H) : 29.50 x 6.50 x 16.00 cm |
| Gross Weight | 0.48 KG |
| Volume | 3,068.00 cm3 |
