คำอธิบาย
| Brand | TP-LINK |
| Model | TL-SG1016 |
| Network Interface | 16 x 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3 |
| Switching Capacity | 32Gbps |
| Transmission Method | Store-and-Forward |
| MAC Address Table | 8K |
| Forwarding Rate | 23.8Mpps |
| Jumbo Frame | 10KB |
| LED Indicators | Power, 1000Mbps, Link/Act |
| Fan Quantity | Fanless |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m) |
| Power Supply | 100-240VAC, 50/60Hz |
| Power Consumption | 9.26W (220V/50Hz) |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
| Certifications | FCC, CE, RoHS |
| Package Contents | 16-Port Gigabit Rackmount Switch Power Cord Installation Guide Rackmount Kits Rubber Feet |
| Dimension | (W x D x H) : 44.00 x 18.00 x 4.00 cm |
| Net Weight | 0.00 KG |
| Package Dimension | (W x D x H) : 25.00 x 53.00 x 9.00 cm |
| Gross Weight | 2.30 KG |
| Volume | 11,925.00 cm3 |
