| Brand | Zyxel |
| Model | GS1900-24HPv2 |
| Network Interface | 24 x GbE PoE RJ-45 ports 2 x GbE SFP slots |
| Standards and Protocols | IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Ethernet IEEE 802.3ab (1000BASE-T) Ethernet IEEE 802.3x flow control IEEE 802.3az EEE support IEEE 802.1p CoS support IEEE 802.3af PoE IEEE 802.3at PoE plus IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) Full-duplex and half duplex, operation with IEEE 802.3x flow ,control and backpressure Store and forward Auto MDI/MID-X |
| Switching Capacity | 52Gbps |
| MAC Address Table | 8K |
| Forwarding Rate | 39Mpps |
| Jumbo Frame | 9K |
| Management | Web interface Remote firmware upgrade by Web Configuration saving and retrieving Firmware upgrade via SNMP DHCP client Daylight saving NTP Port mirroring Scheduled PoE PoE default consumption mode Time range group for scheduled PoE |
| Security | IEEE 802.1x Port security Layer 2 MAC filtering Static MAC forwarding RADIUS TACACS+ SSL Management VLAN CPU defense engine DoS prevention |
| Features | Zyxel One Network Layer 2 Multicast IPv6 Management Traffic Management and QoS |
| PoE | 24 ports PoE 802.3at |
| Power Supply | 100-240VAC, 50/60Hz |
| Power Consumption | Max. 206.5W |
| Environment | Operating Temperature : 0°C to 50°C/ 32°F to 122°F Operating Humidity : 10% to 95%(non-condensing) Storage Temperature : -40°C to 70°C/ -40°F to 158°F Storage Humidity : 10% to 95%(non-condensing) |
| Certifications | EMC, Safety, RoHS |
| Package Contents | GS1900-24HPv2 Power cord Rack mounting kit |
| Dimension | (W x D x H) : 44.10 x 27.00 x 4.40 cm |
| Net Weight | 3.55 KG |
| Package Dimension | (W x D x H) : 62.20 x 35.80 x 10.80 cm |
| Gross Weight | 5.04 KG |
| Volume | 24,049.01 cm3 |
