คำอธิบาย
| Brand | Zyxel |
| Model | GS-105B v3 |
| Network Interface | 5 x RJ-45 LAN 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support |
| Standards and Protocols | IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3 Nway auto-negotiation IEEE 802.3x full duplex operation and flow control IEEE 802.3az Energy Efficient Ethernet |
| Transmission Method | Store-and-forward architecture |
| MAC Address Table | 2 K |
| Jumbo Frame | Jumbo frame support up to 9 KB |
| Packet Buffer Memory | 128 KB |
| Switch Fabric | Switching fabric (non-blocking): 10 Gbps |
| LED Indicators | PWR : Power Per port : Link/Activity – Amber : 10/100 Mbps – Green : 1000 Mbps |
| Features | Auto-MDI/MDIX in all ports Loop detection support Port-based QoS support |
| Power Supply | Input : 100-240 V AC Output : 5 V DC, 1 A |
| Power Consumption | Power consumption: 2.5 watt max. |
| Environment | Operating Environment Temperature: 0°C to 50°C (32°F to 122°F) Humidity: 10% to 90% (Non-condensing)Storage Environment Temperature: -40°C to 70°C (-40°F to 158°F) Humidity: 10% to 95% (Non-condensing) |
| Certifications | CE, FCC Class B, BSMI |
| Package Contents | Gigabit switch Power adapter Quick start guide |
| Package Dimension | (W x D x H) : 10.00 x 13.00 x 9.00 cm |
| Gross Weight | 0.37 KG |
| Volume | 1,170.00 cm3 |
