คำอธิบาย
Brand | Zyxel |
Model | GS1005HP |
Network Interface | 5 x RJ-45 10/100/1000 Mbps Ethernet PoE ports with auto MDI/MDIX support |
Standards and Protocols | IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3 Nway auto-negotiation IEEE 802.3x full duplex operation and flow control IEEE 802.3az Energy Efficient Ethernet |
MAC Address Table | 2 K |
Jumbo Frame | Jumbo frame support up to 9 KB |
Packet Buffer Memory | 128 KB |
Switch Fabric | 10 Gbps |
LED Indicators | PWR : Power PoE MAX : Amber : PoE power output over 50W (total budget 60W) Per port : Link/Activity – Amber : 10/100 Mbps – Green : 1000 Mbps Port1- Port4 : PoE+ Green : PoE supported |
Fan Quantity | ระบายความร้อนโดยไม่ใช้พัดลมระบายอากาศ |
Material | วัสดุภายนอกทำจากโลหะ |
PoE | Standard : 802.3af and 802.3at compliant 4 x PoE+ ports(Port1- Port4), up to 30W per port Total PoE Budget : 60W Compatible With IEEE 802.3af and 802.at Compliant PDs |
Power Supply | AC-to-DC external power adapter Input : 100-240 V AC Output : 55V DC/1.3A |
Environment | Operating Temperature: 0°C to 40°C (32°F to 104°F) Operating Humidity: 10% to 90% (Non-condensing) Storage Temperature: -40°C to 70°C (-40°F to 158°F) Storage Humidity: 10% to 90% (Non-condensing) |
Certifications | CE, FCC, BSMI, EAC |
Package Contents | GbE Unmanaged PoE Switch Power adapter คู่มือการใช้งาน |
Package Dimension | (W x D x H) : 14.00 x 22.00 x 8.00 cm |
Gross Weight | 0.88 KG |
Volume | 2,464.00 cm3 |
