คำอธิบาย
| Brand | LONGWELL |
| Model | H110-D4C (REV.2.0) |
| CPU Support | Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package L3 cache varies with CPU |
| CPU Brand | INTEL |
| Socket | 1151 |
| Chipset | Intel H110 |
| Memory Support | 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR4 2400/2133 MHz memory modules |
| Maximum Memory Bus | 2400 |
| Graphics | Intel® HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz Maximum shared memory of 512 MB |
| Multi Graphic Support | None |
| Audio | Audio Realtek® ALC662 codec High Definition Audio 2/4/5.1-channel |
| Expansion Slots | 1 x PCI Express x16 slot, running at x16 |
| Maximum PCIe Version | PCIe 3.0 |
| Storage | 1 x NVME M.2 4 x SATA 6Gb/s connectors |
| M.2 Storage Type Support | NVMe |
| M.2 Slot | 1 |
| USB | 4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB headers) |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x USB 3.0/2.0 header 2 x USB 2.0/1.1 headers 1 x Clear CMOS jumper |
| Back Panel Connectors | 1 x USB2.0 mouse port 1 x USB2.0 Keyboard port 1 x VGA port 1 x HDMI port 2 x USB 3.0/2.0 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) |
| LAN | Realtek LAN chip (10/100 Mbit) |
| Wireless Data Network | None |
| Form Factor | Micro ATX |
| H/W Monitoring | N/A |
| BIOS | N/A |
| Special Features | N/A |
| Software Features | N/A |
| Operating System Support | N/A |
| Package Contents | มีฝาหลัง+สายSata+Driver |
| Package Dimension | (W x D x H) : 23.00 x 28.00 x 5.50 cm |
| Gross Weight | 0.60 KG |
| Volume | 3,542.00 cm3 |
