NAS QNAP (TS-1232PXU-RP-4G, Without HDD.)

฿71,490.00

  • CPU : AnnapurnaLabs Alpine AL324 ARM® Cortex-A57 4-core 1.7GHz
  • Memory : 4 GB
  • Number of Drives : 12 BAY
  • Quad-core 1.7GHz Rackmount NAS
  • 10GbE SFP+ and 2.5GbE ports
  • Redundant power supply for SMB IT environments
  • HBS (Hybrid Backup Sync) backs up and syncs data to other NAS, servers and cloud storage for comprehensive disaster recovery planning.
  • Increase the storage capacity of the TS-1232PXU-RP with QNAP TR RAID expansion enclosures or TL JBOD.

**โปรดตรวจสอบราคาและจำนวนสินค้ากับพนักงานขายก่อนทุกครั้งที่ทำการสั่งซื้อ เนื่องจากระบบ Stock อาจมีการ Update ล่าช้ากว่าปัจจุบัน และบริษัทฯขอสงวนสิทธิ์ในการเปลี่ยนแปลงข้อมูลสินค้า และราคาโดยมิต้องแจ้งให้ทราบล่วงหน้า

รหัสสินค้า: A0156353 หมวดหมู่: ,

คำอธิบาย

Brand QNAP
Model TS-1232PXU-RP-4G (Without HDD)
CPU Model AnnapurnaLabs Alpine AL324 64-bit ARM® Cortex-A57 4-core 1.7GHz processor, 64-bit ARM
Operating System QTS 5.1.3
System Memory 4GB (1×4 GB) UDIMM DDR4
Drive Interface SATA (2.5″ or 3.5″)
Hot-swappable
Number of Drives 12 x 3.5-inch SATA 6Gb/s, 3Gb/s
Display Panel None
LED Indicators HDD 1-12, Status, LAN, Storage expansion
Interface N/A
USB Interface 4 x USB 3.2 Gen 1
LAN Interface 2 x 2.5 Gigabit Ethernet Port
2 x 10GbE SFP+
Video Video Station
Audio Music Station
Memory Slot 1 x UDIMM DDR4, Up to 16 GB
Buttons Power, Reset
Remote Control PPTP, L2TP/IPSec, OpenVPN, QBelt (QNAP proprietary)
Networking IPv4, IPv6
RAID 8-bay (and more): JBOD, Single, RAID 0, 1, 5, 6, 10, 50, 60
6-bay: JBOD, Single, RAID 0, 1, 5, 6, 10, 50
4-bay: JBOD, Single, RAID 0, 1, 5, 6, 10
2-bay: JBOD, Single, RAID 0, 1
Standard Compliance N/A
Security Domain Security
Security Counselor
OS Support Apple Mac OS 10.10 or later
Ubuntu 14.04, CentOS 7, RHEL 6.6, SUSE 12 or later Linux
IBM AIX 7, Solaris 10 or later UNIX
Microsoft Windows 7, 8, 10 and 11
Microsoft Windows Server 2008 R2, 2012, 2012 R2, 2016, 2019 and 2022
Management Max. Number of Concurrent Connections (CIFS) – with Max. Memory : 700
File system N/A
File Sharing File sharing across Windows, Mac, and Linux/UNIX
Microsoft networking (CIFS/SMB)
Apple networking (AFP)
NFS version 3/4 services
Time Synchronization N/A
Special Features Wake on LAN (WOL) *Only the 2.5GbE port
2U Rackmount
Cooling Fans 2 x 70mm, 12VDC
Power Supply 250W (x2) PSU, 100 – 240V
Power Consumption Operating Mode, Typical : 83.57 W
Environment Operating Temperature : 0 – 40 °C (32°F – 104°F)
Storage Temperature : -20 – 70°C (-4°F – 158°F)
Relative Humidity : 5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
Certification N/A
Packaging Content TS-1232PXU-RP
Ethernet Cable x 1
Power Cord x 2
Flat head screw x 48 (for 3.5″ HDD)
Flat head screw x 36 (for 2.5″ HDD)
Quick Installation Guide (QIG)
Dimension (W x D x H) : 51.10 x 43.20 x 8.86 cm
Net Weight 12.94 KG
