คำอธิบาย
| Brand | TSC |
| Model | TE200 |
| Processor | 400 MHz 32-bit RISC processor |
| Memory | SDRAM : 16 MB Flash : 8 MB |
| Interface | USB 2.0 |
| Display | 1 LED (3 colors: green, amber & red) |
| Decode Capability | 1D bar code Code 128UCC, Code 128 subsets A, B, C, EAN128, Interleaved 2 of 5, Interleaved 2 of 5 with check digit, Code 39, Code 39 with check digit, Code 93, EAN13, EAN8, UPCA, UPCE, EAN and UPC 2 (5) digits add-on, Codabar, Postnet, MSI, MSI with check digit, PLESSEY, China post, ITF14, Code 11, TELEPEN, TELEPENN, PLANET, Code49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS 2D bar code GS1 DataBar, GS1 DataMatrix, Maxicode, AZTEC, PDF417, QR Code, Micro PDF 417 |
| Printing method | Thermal Transfer & Direct Thermal |
| Printing resolution | 8 dots/mm (203 DPI) |
| Printing Speed | 152.4 mm (6″)/second (MAX) |
| Printing Width | 108 mm (4.25″) (MAX) |
| Printing Length | 2,794 mm (110″) (MAX) |
| Paper Size | Media type : Continuous, die-cut, black mark, fan-fold, notched (outside wound) Media width : 20 ~ 112 mm (0.8″ ~ 4.4″) Media thickness : 0.06 ~ 0.19 mm (2.36 ~ 7.48 mil) Media core diameter : 25.4 ~ 38 mm (1″ ~ 1.5″) Media length : 5 ~ 2,794 mm (0.2″ ~ 110″) Media roll capacity : 127 mm (5″) OD |
| Ribbon | Ribbon capacity 300 m long : max. OD 67 mm, 1″ core (ink coated outside) Ribbon capacity 110 m long : max. OD 40 mm, 0.5″ core (ink coated outside) Ribbon Width : 40 mm ~ 110 mm (1.6″ ~ 4.3″) |
| System Support | SAP, Oracle, Windows, Microsoft SQL Server, BarTender, Nice Label |
| Power Supply | External universal switching power supply Input : AC 100-240V, 2.5A, 50-60Hz Output : DC 24V, 2.5A, 60W |
| Package Contents | Quick start guide USB cable Power cord External universal switching power supply 1″ label spindle, fixing tab x2, 1.5″ adapter x 2 1″ ribbon spindle x 2 for 300 m ribbon 1″ ribbon paper core |
| Package Dimension | (W x D x H) : 27.00 x 40.00 x 24.00 cm |
| Gross Weight | 3.70 KG |
| Volume | 25,920.00 cm3 |
