คำอธิบาย
| Brand | Kingston |
| Model | VALUE RAM (KVR32S22D8/32) |
| Memory Size | 32GB |
| Memory Type | DDR4 NB |
| BUS | 3200 NB |
| PC | PC4 25600 NB |
| CL | 22 |
| Chips | 16 |
| Features | • Power Supply: VDD = 1.2V Typical • VDDQ = 1.2V Typical • VPP = 2.5V Typical • VDDSPD = 2.2V to 3.6V • Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals • Low-power auto self refresh (LPASR) • Data bus inversion (DBI) for data bus • On-die VREFDQ generation and calibration • Dual-rank • On-board I2 serial presence-detect (SPD) EEPROM • 16 internal banks; 4 groups of 4 banks each • Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS) • Selectable BC4 or BL8 on-the-fly (OTF) • Fly-by topology • Terminated control command and address bus • PCB: Height 1.18” (30.00mm) • RoHS Compliant and Halogen-Free |
| CPU Brand Support | INTEL/AMD |
| Package Dimension | (W x D x H) : 8.00 x 17.00 x 1.00 cm |
| Gross Weight | 0.05 KG |
| Volume | 136.00 cm3 |
