คำอธิบาย
Brand | ASUS |
Model | ExpertWiFi EBR63 |
Standards | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
Antennas | 4x External Antenna |
Transmit/Receive | 2.4GHz 2×2 5GHz 2×2 |
Frequency | 2.4 GHz 5 GHz |
Interface | 1x RJ45 for Gigabits BaseT for WAN 1x RJ45 for Gigabits BaseT for LAN 1X USB 3.2 Gen 1 1x USB2.0 |
USB Interface | WEB: ASUSWRT APP: ASUS ExpertWiFi APP |
Button | WPS Button, Reset Button, Power Switch |
Memory | 256MB FLASH 512MB RAM |
Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 300 Mbps WiFi 5 (802.11ac) : up to 1734 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps |
Operation Mode | Wireless Router Mode AiMesh Node Mode Access Point Mode |
Firewall | • Maximum Firewall Keyword Filter :64 • Maximum Firewall Network Service Filter :32 • Maximum Firewall URL Filter : 64 |
VPN Support | VPN Client L2PT VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion Support Surfshark |
IPv6 support | YES |
Mounting | Wall Mount Ceiling Mount |
Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 12V with max. 2A current |
Package Contents | – ExpertWiFi EBR63 – RJ45 Ethernet Cable – Power Adapter – Quick Start Guide – Warranty Card – ExpertWiFi EBR63 – RJ45 Ethernet Cable – Power Adapter – Quick Start Guide – Warranty Card |
Dimension | (W x D x H) : 20.50 x 5.20 x 12.70 cm |
Net Weight | 0.43 KG |
