คำอธิบาย
| Brand | ASUS |
| Model | RT-AX3000 V2 |
| Standards | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
| Antennas | External antenna x 4 |
| Transmit/Receive | 2.4GHz 2×2 5GHz 2×2 |
| Frequency | 2.4GH / 5GHz |
| Range | N/A |
| Wireless Functions | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
| Safety Standards | Wi-Fi Encryption : WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise Maximum Guest Network rule : 2.4GHz x3, 5GHz x3 Guest Network Connection time limit Maximum MAC filters : 64 |
| Processor Specs | N/A |
| CPU CORE COUNT | N/A |
| CPU nominal frequency | N/A |
| Size of RAM | 256 MB Flash 512 MB RAM |
| LEDS | 1 x Power 1 x 2.4G 1 x 5G 4 x LAN 1 x WAN |
| Interface | 1 x WAN 10/100/1000 BaseT 4 x LAN10/100/1000 BaseT |
| Optical Fiber | None |
| USB Interface | 1 x USB 3.2 Gen 1 (File System : HFS+, NTFS, vFAT, ext2, ext3, ext4) |
| Button | WPS Button, Reset Button, Power Switch |
| Memory | None |
| Power Switch | Yes |
| Data Rate | 802.11a: สูงสุด 54 Mbps 802.11b: สูงสุด 11 Mbps 802.11g: สูงสุด 54 Mbps 802.11n: สูงสุด 300 Mbps 802.11ac (1024QAM): สูงสุด 1733 Mbps 802.11ax (2.4 GHz): สูงสุด 574 Mbps 802.11ax (5 GHz): สูงสุด 2402 Mbps |
| Operation Mode | Wireless router mode Access point mode Media bridge mode Repeater mode AiMesh node mode ASUSWRT |
| Firewall | Maximum Firewall keyword filter : 64 Maximum Firewall network service filter : 32 Maximum Firewall URL filter : 64 |
| VPN Support | VPN Client OVPN VPN Server OVPN |
| IPv6 support | Yes |
| Features | AiMesh Router APP Alexa AiProtection Pro Parental Control Traffic Control |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 1.75 A current DC Output : 12 V with max. 2 A current |
| Power Consumption | N/A |
| Environment | N/A |
| Package Contents | RT-AX3000 WiFi router RJ-45 cable Power adapter Quick Start Guide Warranty card |
| Package Dimension | (W x D x H) : 33.50 x 26.00 x 8.00 cm |
| Gross Weight | 0.97 KG |
| Volume | 6,968.00 cm3 |
