| Brand | D-LINK |
| Model | DIR-825M |
| Standards | IEEE 802.11 a/b/g/n/ac |
| Antennas | • 2x 5dBi 2.4GHz External Antennas • 2x 5dBi 5GHz External Antennas |
| Frequency | • 2.4GHz • 5GHz |
| Range | • 11N : 2.4-2.4835GHz • 11AC : 5.150-5.825GHz |
| Wireless Functions | • Wireless Client Mode • Wireless AP Mode • Wireless Repeater Mode • Multiple SSID’s • Wireless Schedule |
| LEDS | Status LED |
| Interface | • 1x 10/100/1000 WAN Ethernet • 3x 10/100/1000 LAN Ethernet |
| Button | • WPS button to set up wireless connection • RESET button to restore factory default settings |
| Data Rate | • 2.4GHz: up to 300Mbps • 5GHz: up to 867Mbps |
| Operation Mode | Router / Access Point / Repeater / Wi-Fi Client |
| Management | • Firmware update via web-based interface • • Access settings through WEB GUI • Automatic NTP Date/time from Internet Time Server • Logs and statistics • IPSec/PPTP/L2TP pass-through • Support TR-069 |
| Firewall | • Network Address Translation (NAT) • Stateful Packet Inspection (SPI) • DMZ and Port forwarding(Virtual server) • NAPT and ALG • Denial of Service (DoS) protection • MAC filter • IP filtering |
| VPN Support | OpenVPN/PPTP/L2TP over IPsec |
| Features | • High-Speed Connectivity • Secure Wireless Connection • Flexible Bandwidth • Setup and Management |
| Power Supply | • Input: 12V DC, 1A |
| Environment | • Operating: 10 ~ 90% (non-condensing) Storage: 5 ~ 95% (non-condensing) |
| Dimension | (W x D x H) : 26.35 x 15.07 x 21.45 cm |
| Net Weight | 0.00 KG |
| Package Dimension | (W x D x H) : 28.05 x 27.05 x 5.05 cm |
| Gross Weight | 0.59 KG |
| Volume | 3,831.70 cm3 |
