| Brand | HIKVISION |
| Model | DS-3E1318P-EI |
| Network Interface | • 16× 10/100 Mbps PoE port (230W) • 2× Gigabit combo |
| USB Port | NONE |
| Standards and Protocols | • IEEE 802.3af,IEEE 802.3at |
| Switching Capacity | • Whole-Device Performance: 9.2 Gbps • Port Performance: 7.2 Gbps |
| Transmission Method | • Up to 300 m Long Range PoE Transmission |
| MAC Address Table | 16 K |
| Forwarding Rate | • Whole-Device Performance: 6.84 Mpps • Port Performance: 5.36 Mpps |
| Jumbo Frame | N/A |
| Buffer Architecture | N/A |
| CPU | N/A |
| CPU Memory | N/A |
| Flash Memory | N/A |
| LED Indicators | YES |
| Management | • Support device management via web • Support management via Hik-Central Pro • Support remote management via Hik-Partner Pro |
| VLAN | • VLAN is used for network scale planning and network health improvement. • Support 802.1Q. • Configurable VLAN ID from 1-4094. • Support Trunk, Access port mode. • Support Max. 4094 VLAN. |
| Security | • Ports 1 to 16: port isolation mode to improve network security |
| Firewall | N/A |
| Features | • Support STP/RSTP Loop prevention • Support cable detection to locate failure • Support PoE watchdog to detect and restart the cameras that do not respond |
| MTBF | N/A |
| Fan Quantity | N/A |
| Material | • Metal material |
| PoE | • Max. Port Power : 30W • PoE Power Budget : 230W |
| Power Supply | • 100-240 VAC, 50/60 Hz, Max. 4 A |
| Power Consumption | • Max. Power Consumption : 250 W • Power Consumption in Idle : 20 W • Surge Protection : 6 kV |
| Environment | • Operating Temperature : 0 °C to 45 °C (0 °F to 113 °F) • Storage Temperature : -40 °C to 85 °C (-40 °F to 185 °F) • Operating Humidity : 5% to 95% (no condensation) • Relative Humidity : 5% to 95% (no condensation) |
| Certifications | • CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015) |
| Package Contents | N/A |
| Dimension | (W x D x H) : 44.00 x 22.00 x 4.40 cm |
| Net Weight | 2.59 KG |
