คำอธิบาย
| Brand | HIKVISION |
| Model | DS-3E1309P-EI/M |
| Network Interface | 8× 10/100 Mbps PoE port 1× Gigabit Uplink port |
| Standards and Protocols | IEEE 802.3af,IEEE 802.3at |
| Switching Capacity | 3.6 Gbps |
| MAC Address Table | 8 K |
| Forwarding Rate | 2.6784 Mpps |
| Features | Storm Control : Storm control is used to prevent switch ports from being blocked by broadcast or multicast storms in the LAN, which may affect network communication. Supports port rate limiting based on broadcast, multicast, and unknown unicast packets. DHCP Snooping : DHCP Snooping can prevent unauthorized connections to DHCP servers from disrupting the network and affecting normal network communication, and only allow DHCP packets from trusted ports to pass through Off by default. |
| Material | Metal , fan-free design |
| PoE | PoE Power Budget : 60 W Max. Port Power : 30 W |
| Power Supply | 48VDC, 1.35A |
| Power Consumption | Power Consumption in Idle : 2.5 W Max. Power Consumption : 65 W |
| Environment | Operating Temperature : 0 °C to 40 °C (32 °F to 104 °F) Storage Temperature : -40 °C to 85 °C (-40 °F to 185 °F) Operating Humidity : 5% to 95% (no condensation) Relative Humidity : 5% to 95% (no condensation) |
| Certifications | UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017) |
| Dimension | (W x D x H) : 17.00 x 9.31 x 2.76 cm |
| Net Weight | 0.40 KG |
| Package Dimension | (W x D x H) : 12.50 x 22.00 x 9.50 cm |
| Gross Weight | 0.88 KG |
| Volume | 2,612.50 cm3 |
