| Brand | APC |
| Model | BV1000I-MST |
| Type | Line interactive |
| Rated Capacity | 1000 VA / 600 W |
| Nominal Input Voltage | 230 V |
| Nominal Output Voltage | 230 V |
| Input Frequency | 50/60 Hz +/- 5 Hz auto-sensing |
| Backup Time | N/A |
| Transfer Time | 6 ms typical : 10 ms maximum |
| Display | None |
| Input Connections | 1 x Power Cords |
| Output Connections | 4 x Universal |
| Interface Port | None |
| Indicator & Audible Alam/ Protection | • Alarm when on battery • Distinctive low battery alarm • Overload continuous tone alarm |
| Battery Type | Lead-acid battery |
| Waveform Type | Stepped approximation to a sinewave |
| Typical recharge time | 8hour(s) |
| Battery Replacement | RBC17 |
| Cord Length | 1.20 m |
| Environment | • Operating Temperature : 0 – 40 °C • Operating Relative Humidity : 0 – 90 % • Operating Elevation : 0 – 1999.79meters • Storage Temperature : -20 – 50 °C • Storage Elevation : 0 – 15240meters • Audible noise at 1 meter from surface of unit : 40.0dBA • Protection Class : IP20 |
| Dimension | (W x D x H) : 16.10 x 30.50 x 9.20 cm |
| Net Weight | 5.70 KG |
| Package Dimension | (W x D x H) : 15.00 x 39.00 x 23.50 cm |
| Gross Weight | 6.04 KG |
| Volume | 13,747.50 cm3 |
