คำอธิบาย
| Brand | SYNDOME |
| Model | ECO ll 1000I |
| Type | line interactive |
| Rated Capacity | 1000VA / 500W |
| Nominal Input Voltage | 220 VAC -34%/+27% |
| Nominal Output Voltage | 220V ± 10% |
| Input Frequency | 50/60Hz ±10% |
| Backup Time | 15 – 30 minutes (Depend on load) |
| Transfer Time | 2 ms |
| Display | None |
| Input Connections | None |
| Output Connections | Universal Backup 3 ช่อง Bypass 1 ช่อง |
| Interface Port | None |
| Indicator & Audible Alam/ Protection | On Battery, Low Battery, Overload, Fault |
| Battery Type | Sealed lead acid maintenance free |
| Waveform Type | Simulated Sine Wave at 220Vac +/-10% |
| Typical recharge time | 4-6 hours (90% after fully discharged) |
| Battery Replacement | 1 x 12V 7Ah |
| Features | ผลิตและออกแบบตามมาตรฐาน มอก. |
| Cord Length | N/A |
| Environment | Operating Temperature : ? to 40? Operating Relative Humidity : 0 to 90% |
| Package Contents | 1 x UPS Unit 1 x User Manual |
| Dimension | (W x D x H) : 9.60 x 28.60 x 13.80 cm |
| Net Weight | 4.50 KG |
| warranty | 2*0*2 |
