คำอธิบาย
| Brand | ADVICE |
| Model | S3000 |
| Type | True Online Double Conversion |
| Rated Capacity | 3000 VA / 2700 W |
| Nominal Input Voltage | 200 / 208 / 220 / 230 / 240 VAC |
| Nominal Output Voltage | 208 / 220 / 230 / 240 VAC |
| Input Frequency | 40~70 Hz (50 / 60Hz Auto-Sensing) |
| Backup Time | Long run unit depends on the capacity of external batteries |
| Transfer Time | AC mode to Bat.mode : 0ms Inverter to Bypass : 4ms (Typical) |
| Display | Blue LCD |
| Output Connections | Back up 4 Ports (Backup) |
| Interface Port | • USB • RS232 • SNMPcard (Optional) • Relay card (Optional) |
| Indicator & Audible Alam/ Protection | • Battery mode • Battery Low • Overload • System Fault |
| Battery Type | Depends on the capacity of external batteries |
| Waveform Type | Pure Sinewave |
| Typical recharge time | 4 hours recover to 90% capacity |
| Features | • Online double conversion with full digital control • Wide input voltage range:110~300Vac • input power factor 0.99 with PFC • OUTPUT POWER FACTOR 0.9 • Maximum charging current can be expanded to 12A (Long run unit) • Charging current can be set by LCD • 50Hz/60Hz frequency converter mode • Emergency power off function (EPO) • ECO mode operation for energy saving – Generator compatible • Multiple communication interface:RS232 (USB / EPO / Relay card / SNMP card optional) • Selectable output voltage: 208 / 220 / 230 / 240 Vac • Smart charger design for optimized battery performance • Low priority load disconnection functio0n • 1A or 2A charging current can be selected2a charging current is for 2 groups of inside batteries |
| Dimension | (W x D x H) : 19.10 x 45.00 x 3.37 cm |
| Net Weight | 24.50 KG |
