VPN Router TP-LINK (ER707-M2) Gigabit

฿5,860.00

  • Standards and Protocols : IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
  • Interface
    • 1× 2.5G RJ45 WAN Port
    • 1× 2.5G RJ45 WAN/LAN Port
    • 1× Gigabit SFP WAN/LAN Port
    • 4× Gigabit RJ45 WAN/LAN Ports
    • 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle)
  • Network Media
    • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
    • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
    • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
    • 2500BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
  • Concurrent Session : 500,000
  • New Sessions /Second : 4,200
  • Two 2.5G Ports: 1× 2.5G WAN and 1× 2.5G WAN/LAN ports provide high-bandwidth aggregation connectivity.
  • Up to 6 WAN Ports: 2.5G RJ45, gigabit Fiber, and gigabit RJ45 WAN ports with load balance raise the utilization rate of multi-line broadband.
  • Highly Secure VPN: Enterprise-standard SSL/IPSec/GER§/PPTP/L2TP VPN & OpenVPN are ideal for use across multiple branches and for WFH.
  • Integrated into Omada SDN: Supports Zero-Touch Provisioning (ZTP),** Centralized Cloud Management, Intelligent Monitoring, and more.
  • Centralized Management: Cloud access and Omada app provide the utmost in management convenience.
  • Extensive Security Features: Protect your network and data with advanced firewall policies, DoS defense, IP/MAC/URL filtering, and more security functions.

**โปรดตรวจสอบราคาและจำนวนสินค้ากับพนักงานขายก่อนทุกครั้งที่ทำการสั่งซื้อ เนื่องจากระบบ Stock อาจมีการ Update ล่าช้ากว่าปัจจุบัน และบริษัทฯขอสงวนสิทธิ์ในการเปลี่ยนแปลงข้อมูลสินค้า และราคาโดยมิต้องแจ้งให้ทราบล่วงหน้า

รหัสสินค้า: A0158543 หมวดหมู่: , ,

คำอธิบาย

Brand TP-LINK
Model ER707
Standards • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
Wireless Functions Advanced Routing
• Static Routing
• Policy Routing
Load Balance
• Intelligent Load Balance
• Application Optimized Routing
• Link Backup (Timing§, Failover)
• Online Detection
Bandwidth Control
• IP/Port-based Bandwidth Control
• Guarantee & Limited Bandwidth
NAT
• One-to-One NAT§
• Multi-Net NAT
• Virtual Server
• Port Triggering§
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG
• UPnP
Security
• Attack Defense:
TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN
• Filtering
Web Group Filtering
URL Filtering
Web Security
• ARP Inspection:
Sending GARP Packets
ARP Scanning
IP-MAC Binding
• Access Control
Source/Destination IP Based Access Control
Interface • 1× 2.5G RJ45 WAN Port
• 1× 2.5G RJ45 WAN/LAN Port
• 1× Gigabit SFP WAN/LAN Port
• 4× Gigabit RJ45 WAN/LAN Ports
• 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle)
Button Reset Button
Memory 1 GB DDR4
Management Centralized Management
• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
Maintenance
• Web Management Interface
• Remote Management
• Export & Import Configuration
• SNMP v1/v2c/v3*
• Diagnostics (Ping & Traceroute)§
• NTP Synchronize§
• Syslog Support
Management Features
• Automatic Device Discovery
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration
• ZTP (Zero-Touch Provisioning)
VPN Support IPsec VPN
• 100 IPSec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm
• IKEv1/v2
• MD5, SHA1 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)
PPTP VPN
• PPTP VPN Server
• PPTP VPN Clients (12)
• 60 Tunnels (Shared with L2TP)
• PPTP with MPPE Encryption
L2TP VPN
• L2TP VPN Server
• L2TP VPN Clients (12)
• 60 Tunnels (Shared with PPTP)
• L2TP over IPSec
OpenVPN
• OpenVPN Server
• OpenVPN Clients (6)
• 66 OpenVPN Tunnels
IPv6 support YES
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Mounting Desktop/Wall Mounting
Power Supply 12V/1.5A Adapter
Power Consumption 14.2 W (with USB2.0 connected)
7.1 W (without USB2.0 connected)
Environment • Operating Temperature: 0–40 ? (32–104 ?);
• Storage Temperature: -40–70 ? (-40–158 ?)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% non-condensing
Certification CE, FCC, RoHS
Package Contents • ER707-M2
• Power Adapter
• Quick Installation Guide
Dimension (W x D x H) : 22.60 x 13.10 x 3.50 cm
Net Weight 0.00 KG
Package Dimension (W x D x H) : 24.05 x 33.05 x 7.05 cm
Gross Weight 1.38 KG
Volume 5,603.71 cm3
